Универсальные турбины Turbosystems

Универсальные турбокомпрессоры на шарикоподшипниковой системе для ваших проектов. От дрифт-каров, выпускающих облака дыма, до зверей на драг-стрипе – мы предлагаем широкий ассортимент долговечных и высокоэффективных универсальных турбокомпрессоров для максимальной производительности.
ПОДОБРАТЬ ТУРБИНУ
Power range: 400+ HP

HTD3050B1 универсальный турбокомпрессор для дизельных двигателей

Compressor side:
  • Compressor wheel: 7+7 blades custom reinforced billet;
  • Inducer: 50mm;
  • Exducer: 72mm;
  • Air intake inlet: 63mm / 2.5";
  • Air outlet: 51mm / 2";
Core:
  • custom dual ceramic ball bearing;
  • newest generation variable geometry;
Turbine side:
  • Turbine housing based on BMW e series 170kw 3.0d turbocharger model;
  • Turbine wheel: 9 blades;
  • Inducer: 58mm;
  • Exducer: 54mm;
  • Flange: BMW manifold V-band;
  • Exhaust connection: V-band;
Power range: 400+ HP

HTD3054B2 универсальный турбокомпрессор для дизельных двигателей

Compressor side:
  • Compressor wheel: 7+7 blades custom reinforced billet;
  • Inducer: 54mm;
  • Exducer: 73mm;
  • Air intake inlet: 76mm / 2";
  • Air outlet: 90° 51mm / 2";
Core:
  • custom dual ceramic ball bearing;
  • newest generation variable geometry;
Turbine side:
  • Turbine housing based on BMW F10 3.0d turbocharger model;
  • Turbine wheel: 9 blades;
  • Inducer: 58mm;
  • Exducer: 54mm;
  • Flange: BMW manifold V-band;
  • Exhaust connection: V-band;
Power range: 400+ HP

HTD3254B2 универсальный турбокомпрессор для дизельных двигателей

Compressor side:
  • Compressor wheel: 7+7 blades custom reinforced billet;
  • Inducer: 54mm;
  • Exducer: 77mm;
  • Air intake inlet: 76mm / 3";
  • Air outlet: 90° 51mm / 2";
Core:
  • custom dual ceramic ball bearing;
  • newest generation variable geometry;
Turbine side:
  • Turbine housing based on BMW F10 3.0d turbocharger model;
  • Turbine wheel: 9 blades;
  • Inducer: 58mm;
  • Exducer: 56mm;
  • Flange: BMW manifold V-band;
  • Exhaust connection: V-band;
Power range: 850 - 1100 HP

HTX5574B2 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: 10+0 blades reinforced billet aluminium;
  • Inducer: 74mm, Exducer: 91mm;
  • Intake: 129mm (5");
  • Air outlet: 102mm (4");
Core:
  • Cooling: Water cooled bearing housing with 2 M16x1.5 ports;
  • Bearings: Dual ceramic ball bearings;
Turbine side:
  • Housing: single scroll, AR: 1.15;
  • Turbine wheel: 9 blades;
  • Inducer: 82mm;
  • Exducer: 75mm;
  • Flange: 3" V-band single scroll;
  • Exhaust connection: 4" V-band clamp;
Power range: 850 - 1100 HP

HTX5579B1 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: 10+0 blades reinforced billet aluminium;
  • Inducer: 79mm, Exducer: 98mm;
  • Intake: 129mm (5");
  • Air outlet: 102mm (4");
Core:
  • Cooling: Water cooled bearing housing with 2 M16x1.5 ports;
  • Bearings: Dual ceramic ball bearings;
Turbine side:
  • Housing: twin scroll, AR: 1.45 / 27CM;
  • Turbine wheel: 9 blades;
  • Inducer: 82mm;
  • Exducer: 75mm;
  • Flange: T4 twin scroll;
  • Exhaust connection: 4" V-band clamp;
Power range: 600-1000 HP

HTX4271B1 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: in-house made, reinforced 71/88mm 10+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 63mm (2.5");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll, 19cm2 / AR: 1.02;
  • Turbine wheel: custom design 78.5/70mm 9 blades
  • Flange: T4 twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 600-950 HP

HTX4268B1 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: in-house made, reinforced 68/84mm 10+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 63mm (2.5");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll, AR: 1.02;
  • Turbine wheel: custom design 78.5/70mm 9 blades
  • Flange: T4 twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 600-850 HP

HTX4068B1 универсальный турбокомпрессор для бензиновых двигателей

Displacement of the engine: 1.8-4.0l
Compressor side:
  • Compressor wheel: in-house made, reinforced 68/84mm 10+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 63mm (2.5");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll, AR: 1.02;
  • Turbine wheel: custom design 76/68mm 10 blades
  • Flange: T4 twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 550-750 HP

HTX4064B1 универсальный турбокомпрессор для бензиновых двигателей

Displacement of the engine: 2-3.5l;
Compressor side:
  • Compressor wheel: in-house made, reinforced 64/79mm 10+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 63mm (2.5");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll, 16cm2 / AR: 0.90;
  • Turbine wheel: custom design 76/64mm 10 blades
  • Flange: T4 twin scroll;
  • Exhaust connection: 3" V-band clamp;
не нашли подходящую турбину?

Нажимая на кнопку, вы даете согласие на обработку персональных данных и соглашаетесь c политикой конфиденциальности

Power range: 500-750 HP

HTX4064B2 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: in-house made, reinforced 64/79mm 10+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 63mm (2.5");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 14cm2 / AR: 0.82;
  • Turbine wheel: custom design 76/64mm 10 blades
  • Flange: T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 450-650 HP

HTX3058B1V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake:  101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 8cm2 AR: 0.63;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 2.25" V-band single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 450-650 HP

HTX3058B2V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake:  101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 10cm2 AR: 0.83;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 2.25" V-band single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 450-650 HP

HTX3058B3V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake:  101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 10cm2 AR: 0.83;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 2.25" V-band single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 400-500+ HP

HTX3057B2V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm;
  • (2,5")Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll , 10cm2 AR: 0.73;
  • Turbine wheel: custom design 60/55mm 9 blades
  • Flange: 2.25" V-band single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 400-500 HP

HTX3057B1V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm;
  • (2,5")Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll , 8cm2 AR: 0.61;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 2.25" V-band single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 400-450 HP

HTX2754B1V универсальный турбокомпрессор для бензиновых двигателей

This turbocharger comes with 2 V-band sets (for turbine flange and exhaust).
Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 54/67mm 9+0 blades machined from the solid aluminium;
  • Air Intake diameter:
  • straight compressor housing - 63mm (2,5");
  • compressor housing with 90° elbow - 76mm (3");
  • Air outlet diameter: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooled bearing housing with 2 M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll 8cm2 / AR: 0.61;
  • Turbine wheel: custom design 56/53mm 9 blades;
  • Flange: 2.25" V-band clamp;
  • Exhaust connection: 3" V-band clamp;
Power range: 350-450 HP

HTX2651B1W универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 51/63 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm (2,5");
  • Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 8cm2 AR: 0.61;
  • Turbine wheel: custom design 55/49mm 10 blades;
  • Flange: T25/T2 single scroll;
  • Exhaust connection: "Garrett" style exhaust flange;
Power range: 450-650 HP

HTX3058B2 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 8cm2 AR: 0.61;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 3" T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
не нашли подходящую турбину?
Нажимая на кнопку, вы даете согласие на обработку персональных данных и соглашаетесь c политикой конфиденциальности
Power range: 450-650 HP

HTX3058B3 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll, 12cm2 AR: 0.89;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: T3 twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 450-650 HP

HTX3058B4 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 58/72 mm 9+0 blades machined from the solid aluminium;
  • Intake: 101mm (4");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 12cm2 AR: 0.89;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 350-450 HP

HTX2651B1 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 51/63 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm (2,5");
  • Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 8cm2 AR: 0.61;
  • Turbine wheel: custom design 55/49mm 10 blades;
  • Flange: T25/T2 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 400-500+ HP

HTX3057B2 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm;
  • (2,5")Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll , 8cm2 AR: 0.61;
  • Turbine wheel: custom design 60/55mm 9 blades
  • Flange: T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 450-550 HP

HTX3057B3 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm (2,5");
  • Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: twin scroll , 12cm2 AR: 0.89;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 3" T3 twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 400-450 HP

HTX2754B1 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 54/67mm 9+0 blades machined from the solid aluminium;
  • Air Intake diameter:
  • straight compressor housing - 63mm (2,5");
  • compressor housing with 90° elbow - 76mm (3");
  • Air outlet diameter: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooled bearing housing with 2 M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll 8cm2 / AR: 0.61;
  • Turbine wheel: custom design 56/53mm 9 blades;
  • Flange: T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 470-570 HP

HTX3057B4 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm (2,5");
  • Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll , 12cm2 AR: 0.89;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 3" single twin scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 470-570 HP

HTX3057B5 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Ported shroud compressor housing;
  • Compressor wheel: in-house made, reinforced 57/71 mm 9+0 blades machined from the solid aluminium;
  • Intake:
  • Straight compressor housing - 63mm (2,5");
  • Compressor housing with 90° elbow - 76mm (3");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll , 14cm2 AR: 1.05;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: 3" T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
Power range: 300-450 HP

HTS3057B2 универсальный турбокомпрессор для бензиновых двигателей

Compressor side:
  • Compressor wheel: in-house made, reinforced 57/71 mm 6+6 blades machined from the solid aluminium;
  • Intake: 63mm (2,5");
  • Air outlet: 51mm (2");
Core:
  • Bearings: dual ceramic ball bearings;
  • Cooling: water cooling with 2 x M14x1.5 ports;
  • Lubrication: AN4 oil inlet with integrated oil restrictor;
Turbine side:
  • Housing: single scroll, 8cm2 AR: 0.61;
  • Turbine wheel: custom design 60/55mm 9 blades;
  • Flange: T3 single scroll;
  • Exhaust connection: 3" V-band clamp;
не нашли подходящую турбину?
Нажимая на кнопку, вы даете согласие на обработку персональных данных и соглашаетесь c политикой конфиденциальности
Made on
Tilda
